LR 3 Click is a compact add-on board that contains a long-range transceiver. This board features the 32001345, RF technology-based SRD transceiver, which operates at a frequency of 868MHz from Mipot. Thanks to the spread spectrum modulation feature, as well as the low power consumption, it is capable of achieving long-range communication, immune to interferences. It features a complete long-range stack onboard; it implements physical, network, and MAC layers, allowing for easy operation via the UART interface. The transceiver is also RED 2014/53/EU certified, allowing for easy integration into the final application. This Click board™ offers an easy and reliable solution for developing highly integrated long-range IoT networks, security systems, alarm networks, and similar applications that require simple and reliable networking solutions.
LR 3 Click is supported by a mikroSDK compliant library, which includes functions that simplify software development. This Click board™ comes as a fully tested product, ready to be used on a system equipped with the mikroBUS™ socket.
MIKROE-4616$27.00
LR 15 Click is a compact add-on board designed for ultra-low-power long-range communication in IoT applications. It is based on the Wio-E5-LE, a LoRaWAN® module from Seeed Studio, featuring the STM32WLE5JC SoC and SX126X LoRa® chip for high-performance and energy-efficient operation. This board supports LoRa® and (G)FSK modulation modes, with adjustable bandwidths up to 500kHz, a transmission power of 14dBm, a sensitivity of -136.5dBm, and a 158dB link budget, ensuring reliable long-range connectivity across global LoRaWAN® frequency plans. It also includes advanced features like the Click Snap functionality for modularity, a u.Fl antenna connector for flexible connectivity and SWD support for custom firmware development. Ideal for applications such as wireless meter reading, sensor networks, and low-power wide-area network (LPWAN) systems, LR 15 Click provides a robust and efficient platform for innovative IoT solutions.
LR 15 Click is fully compatible with the mikroBUS™ socket and can be used on any host system supporting the mikroBUS™ standard. It comes with the mikroSDK open-source libraries, offering unparalleled flexibility for evaluation and customization. What sets this Click board™ apart is the groundbreaking ClickID feature, enabling your host system to seamlessly and automatically detect and identify this add-on board, alongside a Click Snap feature introducing a new level of flexibility and ease of use.
MIKROE-6422$29.00
LR 14 Click - 868MHz is a compact add-on board for low-power, long-range wireless communication in IoT networks. This board features the RAK3172, a Class A/B/C LoRaWAN 1.0.3-compliant module from RAKwireless Technology, featuring the STM32WLE5CC ARM Cortex-M4 32-bit chip. This board supports LoRaWAN and LoRa Point-to-Point communication modes and integrates multiple frequency bands for flexibility across various regions. Key features include UART, SPI, and I2C interfaces, a USB Type-C connector for power and configuration, and a rechargeable battery option for standalone operation. Additional functionality is provided by SWD and BOOT buttons for firmware management and configurable GPIO pins for customization. LR 14 Click is ideal for long-distance, low-power communication applications, such as remote sensing, asset tracking, and IoT deployments.
LR 14 Click - 868MHz is fully compatible with the mikroBUS™ socket and can be used on any host system supporting the mikroBUS™ standard. It comes with the mikroSDK open-source libraries, offering unparalleled flexibility for evaluation and customization. What sets this Click board™ apart is the groundbreaking ClickID feature, enabling your host system to seamlessly and automatically detect and identify this add-on board.
MIKROE-6303$55.00
NFC 3 Click is a compact add-on board that contains an NFC transceiver for contactless communication at 13.56MHz. This board features the PN5180A0HN, a highly integrated high-performance full NFC Forum-compliant frontend from NXP Semiconductors. The PN5180A0HN utilizes an outstanding modulation and demodulation concept for different contactless communication methods and protocols. It is fully compliant with many Reader/Writer standards (ISO 14443A/B, ISO 15693, ISO 18092, and more), alongside support for reading all NFC tag types (type 1, 2, 3, 4A, and 4B). Besides the SPI host interface, it also features high RF output power to drive an antenna etched on the PCB directly, besides its tuning circuit, at high efficiency. This Click board™ represents an ideal solution for rapidly integrating NFC technology into any custom application.
NFC 3 Click is fully compatible with the mikroBUS™ socket and can be used on any host system supporting the mikroBUS™ standard. It comes with the mikroSDK open-source libraries, offering unparalleled flexibility for evaluation and customization. What sets this Click board™ apart is the groundbreaking ClickID feature, enabling your host system to seamlessly and automatically detect and identify this add-on board.
MIKROE-5538$47.00
