IPD Click - TPD2015

Type Relay Applications Ideal for developing wearable technology, smart home devices, robotics, and AR/VR applications On-board modules TPD2015FN - 8-channel high-side load switch featuring MOSFET outputs from Toshiba Semiconductor Key Features High-side load switch, CMOS/TTL logic control, protection features, suitable for inductive and resistive loads, inductive load of 50mH max, 0.5A output current per channel, can drive load directly, high-voltage operation, and more Interface GPIO ClickID Yes Compatibility mikroBUS™ Click board size L (57.15 x 25.4 mm) Input Voltage 3.3V or 5V,External
