Achieve high-precision 3D distance measurement and motion tracking with the AFBR-S50 Time-of-Flight (ToF) sensor
LightRanger 7 Click is a compact add-on board capable of precise distance measurement and motion tracking. This board features the AFBR-S50, a medium-range 3D multipixel Time-of-Flight (ToF) sensor from Broadcom. Besides a VCSEL-based ToF sensor (Laser Class 1 eye safety), optimized to measure various distances working equally well on white, black, colored, and metallic reflective surfaces, this board also includes a 32-bit MCU, RA4M2 group of Renesas MCU with Arm® Cortex®-M33 core, alongside a 4-pin standard CAN connections compatible with Pixhawk®, a popular general-purpose flight controller.
This Click board™ makes the perfect solution for robotics and industrial applications requiring precise 3D information and an extended range like drones or AMR/AGV.
For more information about LightRanger 7 Click, visit the official product page.
ABOUT CLICK BOARDS™
Click boards™ follow a modular prototyping add-on board standard invented by MIKROE, which revolutionizes the way users add new functionalities to development boards. Click boards™ enable design engineers to change peripherals easily, cutting months off development time. To enable hundreds of Click boards to be connected to the microcontroller or microprocessor, we have invented socket standard - mikroBUS™. This uniform connection interface allows you to connect any Click boards to a main board instantly. The company releases a new Click boards nearly every day at 10am, and many leading microcontroller companies including Microchip, NXP, Infineon, Dialog, STM, Analog Devices, Renesas and Toshiba now include the mikroBUS™ socket on their development boards.
ABOUT MIKROE
MikroElektronika (MIKROE) is committed to changing the embedded electronics industry through the use of industry-standard hardware and software solutions. In 2011, the company invented the mikroBUS™ development socket standard and the compact Click Boards that use the standard to dramatically cut development time. Now the company offers 1450+ Click Boards – ten times more than competitors - and the mikroBUS standard is included by leading microcontroller companies such as Microchip, Renesas and Toshiba on their development boards. MIKROE defined MCU development add-on boards and socket standard called SiBRAIN, and display board and display socket standard - DISCON. MikroElektronika also makes the world’s widest range of compilers and additionally provides development environments, development boards, smart displays and programmers and debuggers.
