9DOF click carries ST’s LSM9DS1 inertial measurement module that combines a 3D accelerometer, a 3D gyroscope and a 3D magnetometer into a single device outputting so called nine degrees of freedom data...
This product is no longer in stock
9DOF click carries ST’s LSM9DS1 inertial measurement module that combines a 3D accelerometer, a 3D gyroscope and a 3D magnetometer into a single device outputting so called nine degrees of freedom data (3-axis acceleration, angular velocity and heading), in 16-bit resolution. 9DOF click communicates with the target MCU through the mikroBUS I2C interface (SCL and SDA) with additional functionality provided by the programmable Interrupt (INT) pin, as well as the Enable (EN) pin. The IC has multiple interrupt lines which can be accessed through jumpers on the click board. I2C addresses are specified in the same manner. The board uses a 3.3 power supply only.
|Applications||Gesture recognition, navigation, interactive UI|
|On-board modules||ST’s LSM9DS1|
|Key Features||3-axis accelerometer, 3-axis gyroscope and 3-axis magnetometer in one IC. Measuring ±2/±4/±8/±16 g acceleration. ±4/±8/±12/±16 gauss magnetic. ±245/±500/±2000 dps|
|Click board size||S (28.6 x 25.4 mm)|
MEMS sensors or Micro-Electro-Mechanical Systems are the sensors and actuators at the bare metal of embedded systems. MEMS are used for airbag systems, automatic door locks, security systems , earthquake detection, inkjet printers, kitchen appliances, and of course computer peripherals. In this blog we will explore the different ways you can use MEMS sensors.
