Add both WiFi (2.4GHz) and Bluetooth® LE 5 connectivity to your projects with Stephano-I (2617011025000)





Stephano-I Click is a compact add-on board designed to add WiFi and Bluetooth® LE connectivity to any embedded application. This board features the Stephano-I (2617011025000) radio module from Würth Elektronik.



KEY FEATURES:


• Dual radio support: Integrates IEEE 802.11 b/g/n WiFi (2.4GHz) and Bluetooth® LE 5
• Peripheral and central roles (BLE): Supports both peripheral and central modes for Bluetooth® LE
• Simple AT command interface: Provides easy control over UART
• WiFi data rate: Supports data rates up to 150Mbps
• Bluetooth® LE data rate: Supports a 1Mbps data rate
• High output power: Offers WiFi output power up to 13.4dBm and Bluetooth® LE output power up to 4.5dBm



APPLICATIONS:


• Achieve wireless communication with cloud services and other smart devices
• Connect smart home devices and maintain control
• Provide wireless connectivity for industrial sensors and control systems
• Enable low-power communication between sensor nodes
• Support wireless communication for wearable devices
• Any embedded system requiring low-power WiFi and/or Bluetooth® LE connectivity



EmbeddedWiki



Find hundreds of ready-to-use embedded projects featuring this Click board™ on EmbeddedWiki! Jumpstart new designs and simplify your design cycle with by using world's largest embedded projects platform with 1M+ ready-to-use projects.

For more information about Stephano-I Click visit the official product page. Don't forget to come back tomorrow at 10 AM CET, and take a look at our next product release.
