MIKROE-6589
8 g
Status:
BarGraph 1-Cell Red (HLMP-2685) is a high-visibility red light source designed for applications requiring bright and uniform illumination. It is based on the HLMP-2685 LED component from Broadcom Limited, ensuring reliability and efficiency. Featuring a Dual-in-line configuration with a single light-emitting area, it provides a typical luminous intensity of 83.4mcd and operates at a peak wavelength of 626nm. Encased in a single-in-line package, it delivers consistent performance and long-lasting operation. This red light bar is ideal for bargraph displays, front panel process status indicators, telecommunications equipment, and machine message annunciators, offering clear and dependable visual feedback.
NOTE: This bargraph can also be found in an embedded format in combination with the BarGraph 5 Click board™. For more information about this Click board™, visit the BarGraph 5 Click product page.
This product is no longer in stock
Availability date:
OFF
| Company | Stock | Price |
|---|---|---|
BarGraph 1-Cell Red (HLMP-2685) is a rectangular red light source developed by Broadcom Limited, designed to meet the demands of applications requiring a bright and clearly visible light output. This component features a Dual-in-line configuration, incorporating a single light-emitting area that ensures consistent illumination. The LEDs within the light bar are constructed using a GaAsP epitaxial layer diffused onto a GaP substrate, which contributes to its efficient performance and reliability.
Encased in a single-in-line package, this red light bar is well-suited for a wide range of industrial and commercial applications. It provides a typical luminous intensity of 83.4mcd and operates at a peak wavelength of 626nm, delivering exceptional visibility. Thanks to its uniform and intense light output, it is particularly beneficial for applications such as bargraph displays, front panel process status indicators, telecommunications equipment, machine message annunciators, and any other use cases where clear and dependable visual indication is required.
| Specification | |
|---|---|
| Luminous Intensity per Lighting-Emitting Area (mcd): | 210 |
| Peak Wavelength (nm): | 631 |
| Dominant Wavelength (nm): | 622 |
| Forward Voltage per LED (V): | 2.05 |
| Part Number: | HLMP-2685 |
| Color: | Red |
