Large 320x240 TFT Color Display with Touch Screen and Stereo MP3 Codec chip with great performance give you true power to build full multimedia applications.
Board is carefully designed and is very compact and handy. We have used the highest quality components and 4-layer PCB to achieve maximum efficiency.
Charge your batteries directly from USB port. No additional electronics, or expensive adapters. Just plug-in the cable, and this little board will handle the rest
You can save pictures, sounds and other media files on microSD memory card and 8Mbit Serial Flash Memory and use it in your application.
This board provides a compact high-quality multimedia development platform for STM32F407VGT6 device. It has numerous on-board modules, that allow you to write multimedia applications. This board can be used for both development or as a final product.
All you need to get started: Examples, manuals, and bootloader application. Download examples and load them in your mikroMedia to see how it works. Examples demonstrate each on-board module and are a great starting point for your future mikroMedia projects.
Examples are written for all mikroElektronika ARM compilers: mikroC, mikroBasic and mikroPascal.
mikromedia is preprogrammed with a USB-HID bootloader. Just download our mikroBootloader application and you’re ready to upload your firmware.
In case you’re incorporating a mikromedia into a final product, reference this AutoCAD file to simplify designing and building a proper enclosure.
Hover your cursor over the desired module and instantly get more information. Get to know your board even before you buy it. Become a mikroMedia geek.
On-board ADXL345 Digital Accelerometer allows you to measure acceleration.
Plug-in your headphones and listen to audio output from mp3 decoder circuit.
MCP73832 Battery Charger circuit enables you to charge your Li-Polymer battery directly from USB port.
Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.
Every unsused microcontroller pin is available through connection pads. They can be used to connect your mikromedia board with additional shields or accessory boards.
Board contains 32.768kHz Crystal oscillator (X1) which provides external clock for internal RTCC module.
If you place battery shield or integrate your board so that only front TFT is accessible, this reset button can be very handy.
Pads for connecting and programming the board with mikroProg for STM32 external programmer
168MHz (Cortex-M4) operation; 0-wait states execution from 1Mbyte Flash memory, 128kbytes of RAM, low power, rich peripherals, you name it!
microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.
Microcontroller with USB support, allows you to communicate with a PC or other USB devices using USB connection.
VS1053 MPEG audio decoder with SPI interface for fast reproduction of Ogg Vorbis / MP3 / AAC / WMA / FLAC / MIDI audio files.
We have added power indicator LED, so you can be sure whether your board has stable power supply.
On-Board power regulator ensures that each part of the board get the right voltages.
High quality reset button with surrounding reset circuitry ensures stable reset operation.
Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface. It suports over 100,000 Erase/Program Cycles per Sector and has over 20 Year Data Retention.
320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.
Although your mikromedia comes preprogrammed with bootloader, this may not be enough for you. For serious development you need a good debugger. And this is where mikroProg comes handy. It’s fast USB programming and debugging capabilities, outstanding performance and ease-of-use are just what you need. [more info]
mikroMedia for STM32 M4 is packed in the protective box along with the relevant documentation and product DVD. This box is very resistant to all kinds of damages and shocks. The package contains:
mikroMedia for STM32 M4
board in antistatic bag
USB cable and 3 headers
(2x5 and a pair of 1x26)
User Manual and
DVD with documentation
and code examples
