Order Board mikromedia for STM32 M3
mikromedia for STM32®

mikromedia for STM32 M3 - ARM Cortex-M3 Multimedia Development Board

Swiss Army Knife for Multimedia Developers

It sings and dances

Multimedia modules

Large 320x240 TFT Color Display with Touch Screen and Stereo MP3 Codec chip with great performance give you true power to build full multimedia applications.

Multimedia modules

It’s really compact

It fits in your pocket

Board is carefully designed and is very compact and handy. We have used the highest quality components and 4-layer PCB to achieve maximum efficiency.

It fits in your pocket

Just plug-in the USB cable

Battery charger on board

Charge your batteries directly from USB port. No additional electronics, or expensive adapters. Just plug-in the cable, and this little board will handle the rest

Battery charger on board

Many more megabytes

Enough storage

You can save pictures, sounds and other media files on microSD memory card and 8Mbit Serial Flash Memory and use it in your application.

Enough storage
Why choose mikromedia?

Why choose mikromedia?

This board provides a compact high-quality multimedia development platform for STM32F207VGT6 device. It has numerous on-board modules, that allow you to write multimedia applications. This board can be used for both development or as a final product.

Compiler support

Mikromedia for STM32 M3 is fully supported by mikroC, mikroBasic and mikroPascal compilers for ARM. Compilers come with dozens of examples that demostrate every feature of the board.

  • mikroC PRO for ARM
  • mikroBasic PRO for ARM
  • mikroPascal PRO for ARM

Programming

On-board STM32 microcontroller is preprogrammed with fast USB HID bootloader, so it’s ready to work right out of the box. You don’t have to spend a dollar more on programmers. For those who need it, board can also be programmed and debugged using mikroProg™ for STM32 debugger.

Visual TFT

Easily create fantastic colorful graphical user interfaces (GUI) for mikromedia in VisualTFT software. Even total beginners will be able to create amazing applications.

Downloads

All you need to start

Downloads

All you need to get started: Examples, manuals, and bootloader application. Download examples and load them in your mikroMedia to see how it works. Examples demonstrate each on-board module and are a great starting point for your future mikroMedia projects.

Examples

Examples are written for all mikroElektronika ARM compilers: mikroC, mikroBasic and mikroPascal. They are well commented and each example contains working HEX file which you can load and use right away. Examples are available on the Libstock™ website.

What’s on board?

For the geeks

What’s on board?

Hover your cursor over the desired module and instantly get more information. Get to know your board even before you buy it. Become a mikroMedia geek.

Front View Frontal Reset Button TFT with Touch Panel
Accelerometer

Accelerometer

On-board ADXL345 Digital Accelerometer allows you to measure acceleration.

Audio Connector

Audio Connector

Plug-in your headphones and listen to audio output from mp3 decoder circuit.

Battery Charger

Battery Charger

MCP73832 Battery Charger circuit enables you to charge your Li-Polymer battery directly from USB port.

Battery Connector

Battery Connector

Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.

Connection Pads

Connection Pads

Every unsused microcontroller pin is available through connection pads. They can be used to connect your mikromedia board with additional shields or accessory boards.

RTCC Crystal Oscillator

RTCC Crystal Oscillator

Board contains 32.768kHz Crystal oscillator (X1) which provides external clock for internal RTCC module.

Frontal Reset Button

Frontal Reset Button

If you place battery shield or integrate your board so that only front TFT is accessible, this reset button can be very handy.

mikroProg connector

mikroProg connector

Pads for connecting and programming the board with mikroProg for STM32 external programmer

STM32F207(407)VGT6

STM32F207VGT6

120MHz (Cortex-M3) operation; 0-wait states execution from 1Mbyte Flash memory, 128kbytes of RAM, low power, rich peripherals, you name it!

microSD card slot

microSD card slot

microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.

miniUSB connector

miniUSB connector

Microcontroller with USB support, allows you to communicate with a PC or other USB devices using USB connection.

Stereo Audio codec

Stereo Audio codec

VS1053 MPEG audio decoder with SPI interface for fast reproduction of Ogg Vorbis / MP3 / AAC / WMA / FLAC / MIDI audio files.

Power LED

Power LED

We have added power indicator LED, so you can be sure whether your board has stable power supply.

Power Regulator

Power Regulator

On-Board power regulator ensures that each part of the board get the right voltages.

Reset Button

Reset Button

High quality reset button with surrounding reset circuitry ensures stable reset operation.

Serial Flash Memory

Serial Flash Memory

Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface. It suports over 100,000 Erase/Program Cycles per Sector and has over 20 Year Data Retention.

TFT with Touch Panel

TFT with Touch Panel

320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.

Side View Accelerometer Audio Connector Battery Charger Battery Connector Connection Pads RTCC Crystal Oscillator mikroProg connector STM32F207(407)VGT6 microSD card slot miniUSB connector Stereo Audio codec Power LED Power regulator Reset Button Serial Flash Memory
Loading
Package Contains

what do you get

Package Contains

mikroMedia for STM32 M3 is packed in the protective box along with the relevant documentation and product DVD. This box is very resistant to all kinds of damages and shocks. The package contains:

Damage resistant protective box

Damage resistant
protective box

mikroMedia for Stellaris® M3

mikroMedia for STM32 M3
board in antistatic bag

USB cable and ST-Link v7 to mikroProg adapter

USB cable and mikroProg to ST-Link v2 adapter

User Manual and Board Schematic

User Manual and
Board Schematic

DVD with documentation and code examples

DVD with documentation
and code examples
