Large 320x240 TFT Color Display with Touch Screen and Stereo MP3 Codec chip with great performance give you true power to build full multimedial applications.
Board is carefully designed and is very compact and handy. We have used the highest quality components and 4-layer PCB to achieve maximum efficiency.
Charge your batteries directly from USB port. No additional electronics, or expensive adapters. Just plug-in the cable, and this little board will handle the rest.
You can save pictures, sounds and other media files on microSD memory card and 8Mbit Serial Flash Memory and use it in your application.
This board provides a compact high-quality multimedia development platform for PIC32MX460F512L device. It has numerous on-board modules, that allow you to write multimedia applications. This board can be used for both development or as a final product.
Mikromedia for PIC32 is fully supported by mikroC, mikroBasic and mikroPascal compilers for PIC32. Compilers come with dozens of examples that demostrate every feature of the board.
On-board PIC32 is preprogrammed with fast USB HID bootloader, so it’s ready to work right out of the box. You don’t have to spend a dollar more on programmers. For those who need it, board can also be programmed and debugged using the external mikroProg programmer.
Easily create fantastic colorful graphical user interfaces (GUI) for mikromedia in VisualTFT software. Even total beginners will be able to create amazing applications.
All you need to get started: Examples, manuals, and bootloader application. Download examples and load them in your mikroMedia to see how it works. Examples demonstrate each on-board module and are a great starting point for your future mikroMedia projects.
Examples are written for all mikroElektronika PIC32 compilers: mikroC, mikroBasic and mikroPascal. They are well commented and each example contains working HEX file which you can load and use right away. Examples are available on the Libstock™ website.
Hover your cursor over the desired module and instantly get more information. Get to know your board even before you buy it. Become a mikroMedia geek.
Plug-in your headphones and listen to audio output from mp3 decoder circuit.
MCP73832 Battery Charger circuit enables you to charge your Li-Polymer battery directly from USB port.
Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.
8Mhz crystal oscillator circuit that provides external clock is connected to microcontroller osc pins.
If you place battery shield or integrate your board so that only front TFT is accessible, this reset button can be very handy.
Pads for connecting ICD2/3 connector board and programimg the MCU with external programmer.
PIC32MX460F512L is an exceptional 32-bit MCU. 80MIPS power, hardware multiplier and divider, DMA controller and stunning set of integrated modules make this chip a great choice.
microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.
Pads for connecting and programming the board with mikroProg for PIC external programmer
Every unsused microcontroller pin is available through connection pads. They can be used to connect your mikromedia board with additional shields or accessory boards.
We have added power indicator LED, so you can be sure whether your board has stable power supply.
On-Board power regulator ensures that each part of the board get the right voltages.
High quality reset button with surrounding reset circuitry ensures stable reset operation.
Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface.
320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.
PIC32MX460F512L with USB OTG support, allows you to communicate with a PC or other USB devices using USB connection.
You probably think your board is as cool as it gets. Well, we present you with additional accessories that can make your board shine. Give your board the wings it deserves with battery power supply, and purchase industry standard durable microSD card for your multimedia applications. Don’t forget the earphones!
mikromedia workStation v7 provides full development environment for mikromedia boards. It features on-board debugger, multimedia modules, four mikroBUS host sockets and a large breadboard area. Abstract pin names irrelevant of target mikromedia will bring you enormous flexibility and portability of your code for to supported architecture.
$129.00 USD
mikroBUS shield features two mikroBUS host sockets which allow you to connect dozens of Click accessory boards. With this feature, you can provide desired additional functionality to your mikromedia.
$7.50 USD
Connect shield allows you to easily establish connections between your mikromedia board and the surrounding electronics. screw terminals allow you to connect each pin quickly and without soldering.
$16.00 USD
If you are a fan of arcade games, you won’t resist this fantastic board. Gaming shield is an extension board for your mikromedia that provides you with standard gaming buttons and audio speakers, so you can build and play your favorite arcade games. It’s ergonomic design makes sure it comfortably fits in your palms.
$18.00 USD
Battery Boost shield is an extension board that enables autonomous power supply using 2 x AAA batteries. It carrries MCP1640 integrated circuit that provides stable +4.0V power supply voltage.
$14.00 USD
PROTO shield is an extension board that enables users to place components and provide additional functionality to the base board. With connection pads, it’s easy to connect pins to the breadboard area.
$6.90 USD
Need a mass storage in your device? With our microSD card you have 2GB of memory and two additional adapters for full compatibility with your devices.
$11.00 USD
Use plastic telescopic pen for increased precision when working with your touch panel applications. Pen is meant to be used with resistive touch panels only.
$2.00 USD
Get additional 1x26 male pin headers for your mikromedia board. Whether you want to connect it to your prototype board, or you simply need a spear one.
$0.72 USD
Easily connect your mikromedia with additional electronics using wire jumpers. We offer female-to-female, male-to-male and female-to-male single pin wire jumper flavors.
$3.00 USD
These are great! Additional stacking headers might come in handy because they are convenient when you want to stack multiple shields together with your mikromedia board in various ways.
$2.20 USD
Additional female 1x26 socket, in case you need it. Mikromedia board comes with two male 1x26 pin headers, so you might want to get female connectors, in case you come up with some project idea.
$0.90 USD
Perfect solution for your favorite multimedia board or your personal mp3 player. Test your multimedia projects and listen to your favorite tunes.
$5.00 USD
If you need a battery power supply, we have a great and compact solution. This rechargable 2000mAh 3.7V battery can deliver even more. It’s compatible with on-board connector and battery charger.
$13.90 USD
mikroMedia for PIC32 is packed in the protective box along with the relevant documentation and product CD. This box is very resistant to all kinds of damages and shocks. The package contains:
Damage resistant
protective box
mikromedia for PIC32
board in antistatic bag
USB cable
User Manual
and Board Schematic
DVD with documentation
and code examples
Secure online payments provided by 2Checkout.com, Inc. All credit card and personal details are kept secure, and our customer list is not disclosed to any third party.
We deliver our products to all countries in the world using following shipping options:
DHL Express: $25.00 USD for up to 5 Kgs, usually arrives in 2-4 business days.
Post Office $25.00 USD, no weight limit, usually arrives in 7-12 business days.
Note: Please contact local office of the chosen courier about delivery service and possible additional charges.
mikromedia for PIC32
$99.00 USD
Optional:
mikromedia workStation v7
$129.00 USD
mikromedia Starter Kit - PIC32
$199.00 USD
