mikromedia for PIC24 - Development Board for Multimedia

Swiss Army Knife for Multimedia Developers

It sings and dances

Multimedia modules

Large 320x240 TFT Color Display with Touch Screen, Stereo MP3 Codec, and Accelerometer give you true power to build full multimedia applications.

Multimedia modules

It’s really compact

It fits in your pocket

Board is carefully designed and is very compact and handy. We have used the highest quality components and 4-layer PCB to achieve maximum efficiency.

It fits in your pocket

Just plug-in the USB cable

Battery charger on board

Charge your batteries directly from USB port. No additional electronics, or expensive adapters. Just plug-in the cable, and this little board will handle the rest.

Battery charger on board

Many more megabytes

Enough storage

You can save pictures, sounds and other media files on microSD memory card and 8Mbit Serial Flash Memory and use it in your application.

Enough storage
Why choose mikromedia?

Why choose mikromedia?

This board provides a compact high-quality multimedia development platform for PIC24FJ256GB110 device. It has numerous on-board modules, that allow you to write multimedia application of high complexity. Also, it can be used for both development or as a final product.

Compiler support

Mikromedia for PIC24 is fully supported by mikroC, mikroBasic and mikroPascal compilers for dsPIC30/33 and PIC24. Compilers come with dozens of examples that demostrate every feature of the board.

  • mikroC PRO for dsPIC
  • mikroBasic PRO for dsPIC
  • mikroPascal PRO for dsPIC

Programming

On-board PIC24FJ256GB110 is preprogrammed with fast USB HID bootloader, so it’s ready to work right out of the box. You don’t have to spend a dollar more on external programmers. For those who need it, board can also be programmed and debugged using the external mikroProg for PIC programmer.

Visual TFT

Easily create fantastic colorful graphical user interfaces (GUI) for mikromedia in VisualTFT software. Even total beginners will be able to create amazing applications.

Downloads

All you need to start

Downloads

All you need to get started: Examples, manuals, and bootloader application. Download examples and load them in your mikroMedia to see how it works. Examples demonstrate each on-board module and are a great starting point for your future mikroMedia projects.

Examples

Download Examples

Examples are written for all mikroElektronika dsPIC compilers: mikroC, mikroBasic and mikroPascal.

Download Examples

Bootloader

mikromedia is preprogrammed with a USB-HID bootloader. Just download our mikroBootloader application and you’re ready to upload your firmware.

AutoCAD DXF files

In case you’re incorporating a mikromedia into a final product, reference this AutoCAD file to simplify designing and building a proper enclosure.

What’s on board?

For the geeks

What’s on board?

Hover your cursor over the desired module and instantly get more information. Get to know your board even before you buy it. Become a mikroMedia geek.

Front View Front Reset ICD3 Connector mikroProg TFT with Touch Panel
Accelerometer

Accelerometer

On-board ADXL345 Digital Accelerometer allows you to measure acceleration.

Audio Connector

Audio Connector

Plug-in your headphones and listen to audio output from mp3 decoder circuit.

Battery Charger circuit

Battery Charger circuit

MCP73832 Battery Charger circuit enables you to charge your Li-Polymer battery directly from USB port.

Battery Connector

Battery Connector

Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.

Connection pads

Connection pads

Every unsused microcontroller pin is available through connection pads. They can be used to connect your mikromedia board with additional shields or accessory boards.

Front Reset

Frontal Reset Button

If you place battery shiled or integrate your board so that only front TFT is accessible. This reset button can be very handy.

ICD2/3 connector

ICD2/3 connector

Pads for connecting ICD2/3 connector board and programimg the MCU with external programmer.

Microcontroller

Microcontroller

PIC24FJ256GB110 is an exceptional 16-bit MCU. Up to 16 MIPS, single cycle execution, hardware multiplier and divider, USB OTG and stunning set of integrated modules.

mikroProg connector

mikroProg connector

Pads for connecting and programming the board with mikroProg for PIC external programmer

Stereo MP3 codec

Stereo MP3 codec

VS1053 MPEG audio decoder with SPI interface for fast reproduction of MP3 files.

Power Regulator

Power Regulator

On-Board power regulator ensures that each part of the board gets the right voltages.

Reset Button

Reset Button

High quality reset button with surrounding reset circuitry ensures stable reset operation.

microSD card slot

microSD card slot

microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.

Serial Flash Memory

Serial Flash Memory

Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface. It suports over 100,000 Erase/Program Cycles per Sector and has over 20 Year Data Retention.

TFT with Touch Panel

TFT with Touch Panel

320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.

miniUSB connector

miniUSB connector

PIC24FJ256GB110 with USB OTG support, allows you to communicate with a PC or other USB devices using USB connection.

Crystal Oscillator

Crystal Oscillator

8Mhz crystal oscillator circuit that provides external clock is connected to microcontroller osc pins.

Power LED

Power LED

We have added power indicator LED, so you can be sure whether your board has stable power supply.

Side View Accelerometer Audio Connector Battery Charger Battery Connector Connection Pads Microcontroller MP3 Codec Power Regulator Reset Button microSD card slot Serial Flash Memory miniUSB connector Crystal Oscillator Power LED
Loading
Package Contains

what do you get

Package Contains

mikroMedia for PIC24 is packed in the protective box along with the relevant documentation and product DVD. This box is very resistant to all kinds of damages and shocks. The package contains:

Damage resistant protective box

Damage resistant
protective box

mikroMedia for PIC24 board in antistatic bag

mikroMedia for PIC24
board in antistatic bag

USB cable

USB cable

User Manual and Board Schematic

User Manual
and Board Schematic

DVD with documentation and code examples

DVD with documentation
and code examples
