mikromedia for STM32 M4

Name: mikromedia for STM32 M4
Brand: Mikroe
SKU: MIKROE-1102
Price: 178.80 USD
Availability: InStock

Status:

Smart programmable touch 2.8'' display,
packed with features.

Mikromedia can be used for controlling a wide range of applications: from simple hobby projects, up to entire machine installations. It is powered by STM32F407VGT6 microcontroller unit, it gives you true power to build GUI-centric embedded applications.

Main features

Multimedia modules

Large 320x240 TFT Color Display with Touch Screen, Stereo MP3 Codec, and Accelerometer give you true power to build full multimedial applications.

It’s really compact

Board is carefully designed and is very compact and handy. We have used the highest quality components and 4-layer PCB to achieve maximum efficiency.

Just plug-in the USB cable

Charge your batteries directly from USB port. No additional electronics, or expensive adapters. Just plug-in the cable, and this little board will handle the rest.

Many more megabytes

You can save pictures, sounds and other media files on microSD memory card and 8Mbit Serial Flash Memory and use it in your application.

What’s on Board

Click on the desired thumbnail to view full image.

TFT with Touch Panel

320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.

Frontal Reset Button

If you place battery shield or integrate your board so that only front TFT is accessible, this reset button can be very handy.

Audio Connector

Plug-in your headphones and listen to audio output from mp3 decoder circuit.

Battery Charger

MCP73832 Battery Charger circuit enables you to charge your Li-Polymer battery directly from USB port.

Battery Connector

Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.

miniUSB connector

Microcontroller with USB support, allows you to communicate with a PC or other USB devices using USB connection.

Power Regulator

On-Board power regulator ensures that each part of the board get the right voltages.

RTCC Crystal Oscillator

Board contains 32.768kHz Crystal oscillator (X1) which provides external clock for internal RTCC module.

STM32F407VGT6

168MHz (Cortex-M4) operation; 0-wait states execution from 1Mbyte Flash memory, 128kbytes of RAM, low power, rich peripherals, you name it!

Reset Button

High quality reset button with surrounding reset circuitry ensures stable reset operation.

Stereo Audio codec

VS1053 MPEG audio decoder with SPI interface for fast reproduction of Ogg Vorbis / MP3 / AAC / WMA / FLAC / MIDI audio files.

Connection Pads

Every unsused microcontroller pin is available through connection pads. They can be used to connect your mikromedia board with additional shields or accessory boards.

Accelerometer

On-board ADXL345 Digital Accelerometer allows you to measure acceleration.

Serial Flash Memory

Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface. It suports over 100,000 Erase/Program Cycles per Sector and has over 20 Year Data Retention.

Power LED

We have added power indicator LED, so you can be sure whether your board has stable power supply.

mikroProg connector

Pads for connecting and programming the board with mikroProg for STM32 external programmer

microSD card slot

microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.

Why choose mikromedia

Programming

On-board STM32F407VGT6 microcontroller is preprogrammed with fast USB HID bootloader, so it’s ready to work right out of the box. You don’t have to spend a dollar more on programmers. For those who need it, board can also be programmed and debugged using mikroProg™ for STM32 debugger.

Compilers

mikromedia for STM32 M3 is fully supported by mikroC, mikroBasic and mikroPascal compilers for ARM. Compilers come with dozens of examples that demostrate every feature of the board.

GUI design with Visual TFT

Easily create fantastic colorful graphical user interfaces (GUI) for mikromedia in VisualTFT software. Even total beginners will be able to create amazing mikromedia applications.

Modules

Click on the desired thumbnail to view full image.

Power Regulator

On-Board power regulator ensures that each part of the board get the right voltages.

Audio connector and codec

VS1053 MPEG audio decoder with SPI interface for fast reproduction of Ogg Vorbis / MP3 / AAC / WMA / FLAC / MIDI audio files.

microSD card slot

microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SDIO communication.

Microcontroller

168MHz (Cortex-M4) operation; 0-wait states execution from 1Mbyte Flash memory, 128kbytes of RAM, low power, rich peripherals, you name it!

miniUSB connector

Microcontroler supports Full Speed and USB 2.0 OTG, so this connector allows you to communicate with a PC or other USB devices using USB connection.

Battery connector

Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.

Downloads

mikroMedia for STM32® User Manual

mikroMedia for STM32® Schematic

mikroMedia for STM32® Pinout

mikromedia for STM32® M4 example on Libstock

mikroMedia for STM32® USB Bootloader

mikromedia for STM32 AutoCad File

Product Specification

Type	mikromedia 7
Architecture	ARM (32-bit)
Display size	2.8"
Resolution	320x240px
Graphic controller	ILI9341
Touch Screen	Resistive
Silicon Vendor	STM
Frame Type	Standard
Features	Accel,Battery Powered,MP3,SD Card
Display type	mikromedia

Kits

Special Offers enable you to easily get into and explore the STM32 M4 mikromedia world. These offers have been carefully created to suite your needs, no matter whether you are a beginner or experienced user. Pick one of our special offers and get great tools for less money.

TFT Plus Professional Kit
TFT Plus Designer Kit

TFT Developer (C) Kit - STM32 M4

By it now for $430.00
Kit Includes $84.5 worth of FREE products!

mikromedia for STM32 M4 ($99.00)
mikroC for PIC compiler with USB Dongle Licence ($299.00)
Visual TFT License Activation Card ($99.00)
microSD card 4GB with adapter ($11.00)
Plastic Pen for TouchPanel ($2.00)
USB cable ($4.50)
Printed manuals

Check now

TFT Developer (Basic) Kit - STM32 M4

By it now for $430.00
Kit Includes $84.5 worth of FREE products!

mikromedia for STM32 M4 ($99.00)
mikroC for PIC compiler with USB Dongle Licence ($299.00)
Visual TFT License Activation Card ($99.00)
microSD card 4GB with adapter ($11.00)
Plastic Pen for TouchPanel ($2.00)
USB cable ($4.50)
Printed manuals

Check now

TFT Developer (Pascal) Kit - STM32 M4

By it now for $430.00
Kit Includes $84.5 worth of FREE products!

mikromedia for STM32 M4 ($99.00)
mikroC for PIC compiler with USB Dongle Licence ($299.00)
Visual TFT License Activation Card ($99.00)
microSD card 4GB with adapter ($11.00)
Plastic Pen for TouchPanel ($2.00)
USB cable ($4.50)
Printed manuals

Check now

TFT Designer Kit - STM32 M4

Not a programming expert, but you have the talent to build a great user interface? Don't worry! Visual TFT will do the hard job for you. You just focus on the design of you TFT GUIs, and the software will handle the rest..

By it now for $181.00 Kit Includes $34.5 worth of FREE products!

mikromedia for STM32 M4 ($99.00)
Visual TFT - License Activation Card ($99.00)
Plastic Pen for TouchPanel ($2.00)
microSD card 4GB with adapter ($11.00)
USB-B cable ($4.50)
Printed manuals

Check now

Shield - Extension for mikromedia

This is just simple demonstration. You can use many other combinations.

mikroBUS Shield for mikromedia

mikroBUS shield is an extension board pin-compatible with all mikromedia boards, that features two mikroBUS host sockets which allow you to connect dozens of Click boards.

With this feature, you can provide desired additional functionality to your mikromedia board. Prototyping breadboard area is also available for placing additional components and expanding the base functionality with custom features.

Prototyping breadboard area is also available for placing additional components and expanding the base functionality with custom features. Board comes with two 1x26 pin female sockets, as well as four 1x8 female sockets for mikroBUS host connectors.
