Large 320x240 TFT Color Display with Touch Screen, Stereo MP3 Codec, and Accelerometer give you true power to build full multimedial applications.
Board is carefully designed and is very compact and handy. We have used the highest quality components and 4-layer PCB to achieve maximum efficiency.
Charge your batteries directly from USB port. No additional electronics, or expensive adapters. Just plug-in the cable, and this little board will handle the rest.
You can save pictures, sounds and other media files on microSD memory card and use it in your application.
This board provides a compact high-quality multimedia development platform for dsPIC33FJ256GP710A device. It has numerous on-board modules, that allow you to write multimedia applications. This board can be used for both development or as a final product.
All you need to get started: Examples, manuals, and bootloader application. Download examples and load them in your mikroMedia to see how it works. Examples demonstrate each on-board module and are a great starting point for your future mikroMedia projects.
Examples are written for all mikroElektronika ARM compilers: mikroC, mikroBasic and mikroPascal.
mikromedia is preprogrammed with a USB-HID bootloader. Just download our mikroBootloader application and you’re ready to upload your firmware.
In case you’re incorporating a mikromedia into a final product, reference this AutoCAD file to simplify designing and building a proper enclosure.
Hover your cursor over the desired module and instantly get more information. Get to know your board even before you buy it. Become a mikroMedia geek.
On-board ADXL345 Digital Accelerometer allows you to measure acceleration.
Plug-in your headphones and listen to audio output from mp3 decoder circuit.
MCP73832 Battery Charger circuit enables you to charge your Li-Polymer battery directly from USB port.
Li-Polymer battery connector allows you easier connection with your battery. Autonomous power supply will give your mikromedia the wings it deserves.
8Mhz crystal oscillator circuit that provides external clock is connected to microcontroller osc pins.
If you place battery shiled or integrate your board so that only front TFT is accessible. This reset button can be very handy.
FTDI chip allows your mikromedia board to be connected with a PC through USB cable over UART connection.
Pads for connecting ICD2/3 connector board and programimg the MCU with external programmer.
dsPIC33FJ256GP710A is an exceptional 16-bit MCU. Stunning 40 MIPS power, hardware multiplier and divider, DMA controller and stunning set of integrated modules.
microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.
Pads for connecting and programming the board with mikroProg for PIC external programmer
VS1053 MPEG audio decoder with SPI interface for fast reproduction of MP3 files.
Every unsused microcontroller pin is available through connection pads. They can be used to connect your mikromedia board with additional shields or accessory boards.
We have added power indicator LED, so you can be sure whether your board has stable power supply.
On-Board power regulator ensures that each part of the board get the right voltages.
High quality reset button with surrounding reset circuitry ensures stable reset operation.
Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface. It suports over 100,000 Erase/Program Cycles per Sector and has over 20 Year Data Retention.
320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.
Fast on-board FTDI chip with USB connector, allow you to communicate with a PC or other UART devices using USB-UART connection.
mikromedia workStation v7 provides full development environment for mikromedia boards with Microchip microcontrollers. It features on-board debugger, multimedia modules, four mikroBUS host sockets and a large breadboard area. Abstract pin names irrelevant of target mikromedia bring flexibility and portability of your code for to supported architecture. [more info]
mikroMedia for dsPIC33 is packed in the protective box along with the relevant documentation and product CD. This box is very resistant to all kinds of damages and shocks. The package contains:
mikroMedia for dsPIC33
board in antistatic bag
USB cable and 4 headers
(1x5, 1x6, and a pair of 1x26)
and Board Schematic
DVD with documentation
and code examples
