EasyMx PRO v7 for STM32 - ARM Cortex-M3 and Cortex-M4 development board

EasyMx PRO v7 for STM32 ARM

STM32 ARM® just found a new home

Four connectors for each port

Amazing connectivity

EasyMx PRO™ v7 is all about connectivity. Having two different connectors for each port, you can connect accessory boards, sensors and your custom electronics easier then ever before.

Amazing connectivity

Everything is already here

mikroProg™ on board

Powerful on-board mikroProg™ programmer and hardware debugger can program and debug over 180 STM32 devices. You will need it, whether you are a professional or a beginner.

mikroProg™ on board

Much more

Multimedia peripherals

TFT 320x240 with touch panel, stereo mp3 codec, audio input and output, navigation switch and microSD card slot make a perfect set of peripherals for multimedia development.

Multimedia peripherals

For easier connections

mikroBUS™ support

Just plug in your mikroBUS™ board, and it’s ready to work. We picked up a set of the most useful pins you need for development and made a pinout standard you will enjoy using.

mikroBUS™ support

What is EasyMx PRO™ v7 for STM32 ARM®?

EasyMx PRO™ v7 for STM32 ARM® is a full-featured development board for STM32 ARM® Cortex™-M3 and Cortex™-M4 microntrollers. It contains many on-board modules necessary for development variety of applications, including multimedia, Ethernet, USB, CAN and other. On-board mikroProg™ programmer and debugger supports over 180 ARM® microcontrollers. Board is delivered with MCU card containing STM32F107VCT6.

EasyMx PRO v7 for STM32 - ARM Cortex-M3/M4 Development Board

It’s a big difference

mikroProg™ on board

What makes this board so unique is that it comes with powerful on-board mikroProg™ programmer and hardware debugger based on popular ST-LINK v2, capable of programming more than 180 microcontrollers. This makes development with EasyMx PRO™ v7 a whole new experience. Whether you are just a beginner, or a well-trained professional, this remarkable feature is an irreplaceable advantage.

17 on-board modules for all kinds of development

Touch Screen, Buzzer, Temp sensors, USB, CAN

Board has modules for all kinds of development. TFT with Touch Panel, along with stereo mp3 codec allow you to develop multimedia applications. There are 2 USB connectors and 2 USB-UART connectors on the board as well. Piezo buzzer will help you test your sound signalization, and you can use I2C EEPROM, Serial Flash and microSD card slot to store data. DS1820 and LM35 temp sensor sockets are here too.

mikroBUS™ sockets

Supports Click™ Boards

mikroBUS™ sockets

With two mikroBUS™ sockets you can add dozens of new functionality to your board with minimum hardware adjustments. Collection of mikroBUS™ compatible Click Boards is growing rapidly, and we have designed them with great care, so you don’t have to make any complicated settings. Just plug your board in, and you are good to go.

Ethernet on-board

RJ-45 connector

Ethernet on-board

Board is equipped with Ethernet connector
and two signal LEDs which enable you to
utilize ethernet feature of STM32
microcontrollers.

Examples and Manuals

All you need to get started: well commented and easy to understand examples and colour user-friendly manuals. Examples demonstrate each on-board module and are a great starting point for your future projects. User manuals are easy to read, with good explanations and lots of photos.

Examples

Download Examples

Examples are written for all mikroE ARM compilers: mikroC, mikroBasic and mikroPascal. They are well commented and each example contains working HEX file which you can load and use right away.

ARM Compilers

User Manuals

For drivers and software for on-board mikroProg™ programmer and debugger visit Programming tab.

What’s on board

Hover your cursor over the desired module and instantly get more information. Get to know your board even before you buy it.

EasyMx PRO v7 for STM32 Front View Analog Inputs Audio Connectors Button Press Level CAN support DS1820 Temp Sensor Ethernet Connector PORT Headers SMD LEDs Tri-state DIP switches Push buttons LM35 Temp Sensor Microcontroller microSD card slot mikroBUS socket 1 mikroBUS socket 2 mikroProg Stereo MP3 codec Navigation switch Oscilloscope GNDs Piezo Buzzer 3.3V power Supply Programmer USB connector Reset Button Right PORT Headers I2C EEPROM Serial Flash TFT with touch screen USB device connector USB host connector USB-UART 1 Connector USB-UART 2 Connector
ADC potentiometers

ADC potentiometers

You can simulate analog inputs using two provided analog potentiometers which can be connected to each of the 10 supported microcontroller analog input pins.

Audio Connectors

Audio Connectors

Audio connectors enable you to connect headphones and microphone with the audio codec chip and use it in your applications.

Button Press Level

Button Press Level

Use these switches to pull-up or pull-down buttons in each input/output group.

CAN Support

CAN Support

Board contains SN65HVD230 CAN controller chip connected to screw terminal connector. This way you can implement industry-standard CAN communication with your device.

DS1820 Temp Sensor

DS1820 Temp Sensor

Board supports Dallas DS1820 One-Wire digital temperature sensor. You can measure temperatures from -55C to +125C (-67F to +257F), with 0.5C accuracy.

Ethernet Connector

Ethernet Connector

Microcontrollers with internal ethernet support can be connected to this RJ-45 connector to establish ethernet communication.

PORT Headers

PORT Headers

Two male IDC10 port headers are available in each Input/Output group, which is convenient for easier access to any PORT pin.

SMD LEDs

SMD LEDs

Each Input/Output PORT group contains red SMD LEDs with low current consumption of only 1mA. Board contains total of 36 LEDs for PORT pins.

Tri-state DIP switches

Tri-state DIP switches

Tri-state DIP switches are used to enable 4K7 pull-up or pull-down resistor on ony desired PORT pin.

Push buttons

Push buttons

Push buttons in each Input/Output group enable you to have digital inputs on each port pin. Buttons are of high quality and have an exceptional and stable response.

LM35 Temp Sensor

LM35 Temp Sensor

The LM35 is a low-cost precision integrated-circuit analog temperature sensor. It can measure temeperatures from -55C to +150C with 0.25C accuracy at room temperatures.

STM32F107VCT6 MCU

STM32F107VCT6 MCU

ARM® Cortex™-M3 with 72MHz operation; 0-wait states execution from 256Kbytes of Flash memory, 64kbytes of RAM, low power, rich peripherals, you name it!

microSD card slot

microSD card slot

microSD Card slot allows you to store large ammounts of data externally on microSD card using fast SPI communication.

mikroBUS socket 1

mikroBUS socket 1

EasyMx® PRO v7 for STM32 ARM® provides two mikroBUS™ sockets for mikroElektronika Click™ Boards. mikroBUS provides simple and effective Plug-and-Play connectivity solution.

mikroBUS socket 2

mikroBUS socket 2

EasyMx® PRO v7 for STM32 ARM® provides two mikroBUS™ sockets for mikroElektronika Click™ Boards. mikroBUS provides simple and effective Plug-and-Play connectivity solution.

mikroProg

mikroProg

On-board mikroProg™ In-Circuit Debugger and programmer is supports over 180 STM32 ARM® Cortex-M3™ microcontrollers from STMicroelectronics®

Stereo MP3 codec

Stereo MP3 codec

VS1053 MPEG audio codec with SPI interface is available for audio input and output. Codec supports many compression file formats.

Oscilloscope GNDs

Oscilloscope GNDs

Three separate GND pins are available on the board for easier connection of GND reference for oscilloscope probes.

Piezo Buzzer

Piezo Buzzer

With piezo buzzer you can debug your applications, or have audio signalization feature. It can be connected to two digital output pins, one of which is the output of PWM module.

3.3V power Supply

3.3V power Supply

Board is equipped with power supply unit capable of supporting 3.3V microcontrollers and peripherals. Board can be powered over USB cable, or external adapter connectors.

Programmer USB connector

Programmer USB connector

Programmer USB connector is connected to on-board mikroProg™, but can also be used to power the board, when the J9 jumper in the Power Supply section is in the USB position

Reset Button

Reset Button

High quality reset button with surrounding reset circuitry ensures stable reset operation.

Right PORT Headers

Right PORT Headers

We have provided additional PORT header on the right side of the board, so you can now access the desired microcontroller pins on the other side of the board too.

I2C EEPROM

I2C EEPROM

You can store 8x256 bytes of configuration data or other data into on-board 24AA01 Serial EEPROM with I2C interface.

Serial Flash

Serial Flash

Store up to 8 Mbit of data in EN25F80 Serial Flash Memory with 25 MHz SPI Bus Interface. It suports over 100,000 Erase/Program Cycles per Sector and has over 20 Year Data Retention.

TFT Display with Touch Panel

EasyTFT Board

EasyTFT is delivered with the board. It contains 320x240 TFT Color Display with Touch Panel can display vivid and clear color images or advanced graphic content.

USB device connector

USB device connector

USB Device Connector is used for connecting the board with other devices such as PC using fast USB 2.0 communication.

USB host connector

USB host connector

USB Host Connector enables your device to behave as USB host. You can communicate with other USB slave devices, such as Flash Sticks, cameras, mp3 players and more.

USB-UART 1 Connector

USB-UART 1 Connector

Fast on-board FTDI chip with USB connector, allows you to communicate with a PC or other UART devices using USB-UART connection.

USB-UART 2 Connector

USB-UART 2 Connector

Fast on-board FTDI chip with USB connector, allows you to communicate with a PC or other UART devices using USB-UART connection.

Supported Devices

On-board mikroProg™ currently supports ARM® Cortex™-M3 and Cortex™-M4 microcontrollers from STM32. Browse through the list of supported devices or use the search box to filter out the microcontrollers or families you are interested in. For example, by typing "STM32F1" will leave only STM32F1XXXXX microcontrollers in the list. More detailed search string will leave more narrow list of devices in the list box.

Device
Name
Device Pin
Count
Program
Memory (KB)
CPU Speed
(Mhz)
RAM
(KB)
Debug
Supported

Add-On Boards

Equip your EasyMx PRO™ v7 for STM32 ARM® board with accessories. Add temperature sensors, UART and USB cables, and use wire jumpers for additional testing and connections.

Loading

You might also need

Equip your EasyMx PRO™ v7 for STM32 ARM® board with accessories. Add temperature sensors, UART and USB cables, and use wire jumpers for additional testing and connections.

USB-B cable

USB-B cable

Get additional cable for your USB or USB-UART connection. We offer 1.8m long high-quality cable with transparent silicon insulation, which supports USB 2.0 data rates.

$4.50

Buy Now!
Added to cart!
Ethernet Roll cable

Ethernet Roll cable

Transparent ethernet cable (1m long) with roll-patent mechanism. It’s equipped with two RJ45 male connectors compatible with computers, routers, modems and development boards.

$3.99

Buy Now!
Added to cart!
DS1820 Temp Sensor

DS1820 Temp Sensor

Expand your EasyMx PRO™ v7 functionality by adding DS1820 1-wire digital temperature sensor with -55°C to +128°C temperature range, and ±0.5°C accuracy. Sensor comes in TO-92 packaging.

$7.40

Buy Now!
Added to cart!
LM35 Temp Sensor

LM35 Temp Sensor

LM35 is the analog temperature sensor supported by EasyMx PRO™ v7, whose output voltage is lineary proportional to the Celsius temperature. It has -55°C to +150°C temperature range, and ±0.75°C accuracy.

$3.50

Buy Now!
Added to cart!
Plastic Pen

Plastic Pen

Use plastic telescopic pen for increased precision when working with your touch panel applications. This Plastic Pen is meant to be used with resistive touch panels only.

$2.00

Buy Now!
Added to cart!
Wire Jumpers

Wire Jumpers

Easily connect your EasyMx PRO™ v7 with additional electronics using wire jumpers. We offer femate-to-female, male-to-male and female-to-mail single pin wire jumper flavours.

$3.00

Buy Now!

Package Contains

EasyMx PRO™ v7 for STM32 ARM® is packed in the protective box along with the relevant documentation and product DVD. This box is very resistant to all kinds of damages and shocks. The package contains:

Damage resistant protective box

Damage resistant
protective box

EasyMx PRO™ v7 board in antistatic bag

EasyMx PRO™ v7 board in
antistatic bag

USB cable

USB cable

User Manuals

User Manual and
Board Schematic

DVD with documentation and code examples

DVD with documentation
and code examples

2Checkout.com - Secure Online Payments

Secure online payments provided by 2Checkout.com, Inc. All credit card and personal details are kept secure, and our customer list is not disclosed to any third party.

We deliver our products to all countries in the world using following shipping options:

DHL Express Delivery

DHL Express: $25.00 USD for up to 5 Kgs, usually arrives in 2-4 business days.

Post Office Delivery

Post Office $25.00 USD, no weight limit, usually arrives in 7-12 business days.

Note: Please contact local office of the chosen courier about delivery service and possible additional charges.

CUSTOMIZATION: We can modify our products to suit your requirements, click here for details.

MIKROE-1099

EasyMx PRO™ v7 for STM32

$169.00 USD
